Excerpt:
Odipie 12V 400Ah LiFePO4 battery delivers 5.12 kWh deep-cycle power, 200A BMS, 5000 cycles—lighter than lead-acid. Perfect for solar, RV, marine, telecom and off-grid seeking low-maintenance, high-density energy storage.
Features
5.12kWh Usable Energy: One 12.8V 400Ah LiFePO4 block equals four 12V 100Ah packs in parallel, cutting wiring, cost and rack space.
200A BMS & 400A peak: Over-charge, -discharge, -current, short-circuit & high-temp.
Operate temperature.: discharge –20–60°C
Target Applications
- Solar / commercial storage
- RV, camper, caravan, marine & off-grid cabins
- Portable power carts
Note: This classic is intended for energy storage and deep cycle use only; it is not suitable for high-amperage cranking applications like starting engines or golf carts.
Charging Methods
- LiFePO4 Smart Charger: 14.6V
Parameters
| Model | 12V 400Ah Marine LFP Battery |
|---|---|
| Nominal voltage | 12.8V |
| Nominal capacity | 400Ah |
| Nominal energy | 5.12kWh |
| Operation voltage range | 10V~14.6V |
| Charge voltage | 14.6V |
| Standard charging current | 80A |
| Max. continuous charging current | 200A |
| Standard discharging current | 80A |
| Max. continuous discharging current | 200A / 300A (Optional) |
| Communication | RS485 / CAN bus (Parallel Communication) |
| Waterproof Level | IP67 |
| Cycle life | 5000 cycles (0.2C charge and discharge) |
| Weight | ≈42kg |
| Dimension(W*H*D) | 520*267*220mm |
| Operation temperature range | -20 ~ 60℃ |
