Odipie 12V 400Ah LiFePO₄ battery delivers 5.12 kWh, 250 A BMS, 5,000 cycles and -20 °C self-heating in an IP67, 42 kg module. Bluetooth monitoring and UN38.3 certification make it the ideal maintenance-free energy-storage solution for solar, RV, marine and industrial distributors.
Features
5120 Wh Energy Density: Packs 5.12 kWh into a single 37.5 kg module—40 % lighter than four 100 Ah lead-acid packs—saving freight cost and install space.
5,000-cycle LiFePO₄ Core: Grade-A cells deliver 3–5× the cycle life of AGM, stabilising dealer warranty exposure and customer ROI.
-20 °C Self-Heating: Integrated warming film draws <1 A from charger to keep cells above 0 °C, eliminating cold-weather returns.
IP67Flame-Retardant ABS: Dust-tight, splash-proof, UV-stable casing slashes field failures in marine, mining and rooftop installs.
<3 % Monthly Self-Discharge: Shelf-stable inventory for distributors; 1C charge ready for fast turn-around on rental fleets.
Target Applications
- Off-grid solar
- RV, caravan & camper van house circuits
- sailing house banks
- Telecom, CCTV & remote industrial cabinets
- Note: This classic is intended for energy storage and deep cycle use only; it is not suitable for high-amperage cranking applications like starting engines or golf carts.
Parameters
| Model | 12.8V 400Ah RV LFP |
|---|---|
| Nominal voltage | 12.8V |
| Nominal capacity | 400Ah |
| Nominal energy | 5.12kWh |
| Operation voltage range | 10V~14.6V |
| Charge voltage | 14.6V |
| Standard charging current | 80A |
| Max. continuous charging current | 200A |
| Standard discharging current | 80A |
| Max. continuous discharging current | 200A / 300A (Optional) |
| Communication | RS485 / CAN bus (Parallel Communication) |
| IP ratings | IP67 |
| Cycle life | 5000 cycles (0.2C charge and discharge) |
| Weight | ≈42kg |
| Dimension(W*H*D) | 520*267*220mm |
| Operation temperature range | -20 ~ 60 ℃ |
