Excerpt:
Odipie 25.6 V 200 Ah LiFePO4 battery delivers 5.12 kWh, 5000+ deep cycles and 200 A continuous discharge in 70 % lighter, 45 % smaller footprint than AGM. Built-in 200 A BMS, IP67 housing, -20–60 °C operating range. Ideal for solar off-grid, e-mobility—storage & deep-cycle only, no engine cranking. Quick MPPT or inverter charging.
Features
Drop-in GC2/GC8 Size: Odipie 51.2 V 100 Ah LFP slides straight under the seat—no tray mods, no extra cables.
5.12 kWh Energy Density: One module replaces eight 12 V AGM, cutting 80 % weight and 50 % volume for the same 1 C output.
≥5 000 Cycles @ 80 % DoD: Delivers a 15-year calendar life even in daily solar cycling.
IP65 Armor: Dust-tight, jet-water resistant, UV-stabilized ABS case with UL94 V-0 flame rating.
<2 % Monthly Self-Discharge: Stock-friendly for distributors—12-month warehouse shelf life without top-up charge.
Target Applications
- Marine & trolling packs—IP65 wash-down proof, no acid spills, 1/3 the weight of AGM.
Note: This classic is intended for energy storage and deep cycle use only; it is not suitable for high-amperage cranking applications like starting engines or golf carts.
Parameters
| Model | 51.2V 100Ah Marine LFP |
|---|---|
| Nominal voltage | 51.2V |
| Nominal capacity | 100Ah |
| Nominal energy | 5.12kWh |
| Operation voltage range | 40-58.4V |
| Charge voltage | 58.4V |
| Standard charging current | 20A |
| Max. continuous charging current | 100A |
| Standard discharging current | 20A |
| Max. continuous discharging current | 100A |
| Communication | RRS485 /CANbus (Parallel Communication) / Dry contact |
| IP ratings | IP67 |
| Cycle life | 5000 cycles (0.2C charge and discharge) |
| Weight | ≈42kg |
| Dimension(W*H*D) | 520x267x220mm |
| Operation temperature range | -20 ~ 60 ℃ |
