Excerpt:
Odipie 12 V 200 Ah LiFePO4 deep-cycle battery—EV-grade A+ cells, 200 A BMS, 2.56 kWh, 4000+ cycles, 48 lbs, IP67. Ideal for solar, RV, marine.
Features
EV-Grade A+ LiFePO4 Cells: Automotive-level chemistry delivers 40 % higher energy density, 10-year service life, 4000+ deep cycles at 60 % DoD.
Smart BMS: Active balancing, 8-fold protection—over-charge, over-discharge, over-current, short-circuit, high/low temp, overload, cell-mismatch, surge.
2.56 kWh Usable Energy: Only 48 lbs, 1/3 the weight of equivalent AGM, doubles runtime for OEM drop-ins.
Zero-Maintenance Design: No memory effect, <3 % monthly self-discharge, handles 2 C bursts for 3 min without shutdown.
Target Applications
- Solar home & off-grid kits – Parallel expansion possible for installers.
- RV, camper, marine house power – 30–70 lb trolling motor support with 200 A continuous draw.
- Telecom & UPS backup – 24/7 float service, instant switch-over.
Note: This classic is intended for energy storage and deep cycle use only; it is not suitable for high-amperage cranking applications like starting engines or golf carts.
Parameters
| Model | 12V 200Ah RV LFP |
|---|---|
| Nominal voltage | 12.8V |
| Nominal capacity | 200Ah |
| Nominal energy | 2.56kWh |
| Operation voltage range | 10V~14.6V |
| Charge voltage | 14.6V |
| Standard charging current | 40A |
| Max. continuous charging current | 200A |
| Standard discharging current | 40A |
| Max. continuous discharging current | 200A |
| Communication | RS485 / CAN bus (Parallel Communication) |
| IP ratings | IP67 |
| Cycle life | ≥4000 cycles |
| Weight | ≈22kg |
| Dimension(W*H*D) | 384*194*255mm |
| Operation temperature range | -20 ~ 60 ℃ |
