Excerpt:
Odipie 51.2 V 100 Ah LiFePO₄ battery delivers 6000+ cycles, –20-60 °C operation, six-layer safety. Perfect for solar home ESS; not for engine cranking.
Features
Ultra-Long Cycle Life: 6000+ deep cycles 80 % DOD keeps ownership cost below 0.05 $/kWh—ideal for bulk-buy dealers who quote lifetime ROI.
Wide Temperature Tolerance: Charge 0-50 °C, discharge –20-60 °C.
Six-Layer Safety Suite: short-circuit, over-current, over-voltage, low-voltage & high-temp protections built-in; stock and ship without add-on BMS.
Target Applications
- Solar home ESS—daytime harvest, night-time offset, 10-year warranty backs homeowner ROI claims.
- LiFePO₄ chemistry eliminates yearly lead-acid swap-outs, slashing OPEX for EPCs.
Note: This classic is intended for energy storage and deep-cycle use only; it is not suitable for high-amperage cranking applications like starting engines or golf carts.
Parameters
| Model | 51.2V 200Ah Rack-Mount LFP |
|---|---|
| Nominal voltage | 51.2V |
| Nominal capacity | 200Ah |
| Nominal energy | 10.24kWh |
| Operation voltage range | 40V~58.4V |
| Charge voltage | 58.4V |
| Standard charging current | 40A |
| Max. continuous charging current | 100A |
| Standard discharging current | 40A |
| Max. continuous discharging current | 100A / 200A(Optional) |
| Communication | RS485 /CAN /Dry contact / RS232 (Optional) |
| IP ratings | IP20 |
| Cycle life | 6000 cycles |
| Weight | ≈85kg |
| Dimension(W*H*D) | 520*500*236mm |
| Operation temperature range | -20 ~ 60 ℃ |
Charging Methods
0.5 C CC/CV to 58.4 V finishes in < 2 h for daytime solar surplus.
